Fuzzy Logic Explained: A Practical Guide to Fuzzy Control Systems

Understanding Fuzzy Control: The Technology Behind Intelligent Automation

Fuzzy control is a technology that allows machines to make decisions in a more human-like way, dealing with imprecise or vague information. It's the secret behind how some air conditioners automatically adjust to the most comfortable temperature. This article will explain the core concepts and workings of fuzzy control in detail.

The Essence of Fuzzy Logic

Traditional logic relies on binary judgments: true or false, 1 or 0. Fuzzy logic, however, acknowledges the "gray areas" that exist in real-world situations. Instead of simply categorizing something as "old" or "not old," fuzzy logic allows for degrees of truth.

• Degrees of Truth: Fuzzy logic uses values between 0 and 1 to represent the degree to which something is true. For example, 0.2 might indicate "slightly old," 0.5 "moderately old," and 0.9 "very old." This allows computers to understand and respond to information in a more nuanced way, similar to human thinking.

How Fuzzy Control Works: A Four-Step Process

The fuzzy control system operates in four main stages:

1. Fuzzification: Converts precise input values into fuzzy language variables. For example, a temperature of 32 degrees Celsius might be translated to "a little hot" or "very hot."
2. Fuzzy Engine: Interprets the fuzzy language of the input. For instance, it might analyze "if the temperature is very high and the humidity is very high..."
3. Fuzzy Rules: Applies a predefined set of rules to make a reasoned judgment based on the fuzzy input. An example rule might be: "If it is hot and humid, then turn on the fan to the maximum."
4. Defuzzification: Converts the fuzzy output back into a precise value that can be executed by a machine. For example, the inferred output might be translated to "set the fan speed to 2100 RPM."

Application: Greenhouse Environmental Control

Imagine using fuzzy control in a greenhouse to maintain a comfortable environment for plants. The system would consider temperature, humidity, and use industrial fans to adjust the conditions.

Fuzzification in Detail: Converting Numbers to Language

The first step, fuzzification, involves translating numerical data into human-understandable language.

• Language Variables: These are terms that describe the input values in a fuzzy way. For temperature, we might use "cold," "comfortable," and "hot." For humidity, we might use "dry", "comfortable", and "humid."

• Membership Functions: These define the degree to which a particular input value belongs to a specific language variable. For example, a temperature of 24°C might have a membership value of 0.33 in the "cold" set and 0.67 in the "comfortable" set.

• Defining Temperature Ranges:

  • Cold: Temperatures below 26°C start to feel cold, becoming "really cold" (degree of 1) below 20°C.

  • Comfortable: The ideal temperature is 26°C (degree of 1), with comfort decreasing as the temperature moves away from this point within the range of 20°C to 32°C.

  • Hot: Temperatures above 26°C start to feel hot, reaching "really hot" (degree of 1) above 32°C.

Defining Humidity Sensations and Output Index

• Defining Humidity Ranges:

  • Comfortable: Humidity between 40% and 60% is most comfortable, with 50% being ideal.

  • Dry: Humidity below 50% feels slightly dry, becoming "really dry" below 40%.

  • Humid: Humidity above 50% feels gradually humid, becoming "really humid" above 60%.

• Output Power: The output, such as fan speed, is also divided into fuzzy categories: low, medium, and high. For example:

  • Low: Power less than 50%, "completely low wind speed" less than 20%.

  • Medium: Wind speed between 30% and 70%, ideal at 50%.

  • High: Power more than 50%, "very strong peak speed" at 80%.

Building a Fuzzy Rulebook

The fuzzy rulebook is a collection of "if-then" rules that define how the system should respond to different combinations of input conditions.

• Example Rules:

  • IF temperature is cold AND humidity is dry, THEN fan speed is low.

  • IF temperature is hot AND humidity is humid, THEN fan speed is high.

• The foggy controller will use these rules to determine the current temperature and humidity to determine how strong the wind should blow. The entire rule table is based on our awareness and experience of the humidity of the environment.

The Fuzzy Inference Engine

The fuzzy engine finds all the appropriate conditions in the foggy rulebook according to the current situation. Then follow the logical reasoning to get a result of a fog output. The formula to be used is the smallest inference factory that is most commonly used.

Defuzzification: Converting Fuzzy Outputs to Actionable Values

Defuzzification converts the fuzzy output into a precise value that can be used to control a device. Two common methods are:

• Center of Gravity Method: Calculates the center point of the fuzzy output area. This point represents the crisp (non-fuzzy) output value.

• Maximum Average Method: Averages the maximum values of the output membership functions. This method is faster but may be less accurate.

Verification: Ensuring Rulebook Accuracy

To check for design errors, the output of the entire rulebook can be visualized as a 3D pattern. A continuous and smooth pattern indicates a correct design. Interruptions or unusual movements suggest errors in the rulebook or program.

Fuzzy control is a powerful tool for creating intelligent systems that can adapt to complex and uncertain environments. By mimicking human-like reasoning, it enables machines to make more informed and nuanced decisions.
