This article explores the evolution of NVIDIA's Tensor Core technology, a key driver in accelerating deep learning computations. We'll examine how Tensor Cores have evolved from the Volta architecture to the latest Blackwell architecture, overcoming computational bottlenecks and reshaping the AI landscape.

Understanding Parallel Computing Fundamentals

Before diving into Tensor Core evolution, it's crucial to understand the principles of parallel computing, which are fundamental to the technology's success.

Amdahl's Law

Amdahl's Law, proposed by Gene Amdahl, dictates the limitations of parallel computing speedup. The law states that the speedup is limited by the serial portion of a task.

• The formula for Amdahl's Law highlights that even with increased parallel resources, the overall speedup plateaus due to the unavoidable serial execution time.

• Even if parallel computing resources are significantly increased, the overall speedup will approach the inverse of the serial processing percentage.

Strong Scaling vs. Weak Scaling

Two key concepts in parallel computing are strong scaling and weak scaling.

• Strong Scaling: Focuses on reducing execution time for a fixed problem size by adding more computational resources. The acceleration is quantified by Amdahl's Law.

• Weak Scaling: Simultaneously increases problem size and computational resources to maintain constant execution time. This is useful in big data contexts. For example, doubling the data size while also doubling compute resources.

The "Memory Wall" Bottleneck

A major challenge in parallel computing is the "memory wall," the disparity between the speed of computation units and the speed of data access from memory (DRAM).

• Processors can execute instructions very quickly, but retrieving data from DRAM is significantly slower, resulting in a bottleneck. This results in much of the time being spent on data access instead of computation.

• NVIDIA Tensor Cores are designed to address this challenge by reducing data movement and improving computational efficiency.

Tensor Core Evolution: A Generational Overview

Volta Architecture (2017): The First Generation

The first generation of Tensor Cores was introduced with the Volta architecture in 2017, marking a significant step in accelerating deep learning tasks.

• Volta addressed the inefficiencies of traditional architectures in handling the large matrix operations common in deep learning.

• It introduced the Half-Precision Matrix Multiply Accumulate (HMMA) instruction as a core innovation.

• Each Streaming Multiprocessor (SM) included 8 Tensor Cores, supporting 4x4x4 matrix multiplication, providing 1024 FLOPS per SM per cycle.

• Volta supported mixed-precision training (FP16 input, FP32 accumulation), balancing speed and accuracy.

Turing Architecture: Expanding Low-Precision Capabilities

The Turing architecture built upon Volta by adding INT8 and INT4 precision support to the second-generation Tensor Cores.

• It broadened low-precision computing capabilities and introduced Deep Learning Super Sampling (DLSS) to gaming graphics.

• The architecture supported new warp-level synchronized MMA operations laying the groundwork for future parallel computing paradigms.

Ampere Architecture (2020): Asynchronous Data Copy and BF16 Support

The third-generation Tensor Cores in the Ampere architecture focused on improving computational performance and efficiency.

• The key innovation was the introduction of asynchronous data copy (cp async), which allows data to be loaded directly from global memory to shared memory, reducing register pressure.

• Although each SM had fewer Tensor Cores (4), the performance of each Tensor Core was doubled, providing 2048 FLOPS per SM per cycle.

• Ampere also supported the BF16 data format, balancing dynamic range and computational cost, which lead to the industry-wide adoption of the format.

Hopper Architecture (2022): Thread Block Clusters and Tensor Memory Accelerator

The fourth-generation Tensor Cores in the Hopper architecture brought significant advancements in both performance and functionality.

• It introduced the concept of Thread Block Clusters, allowing CTAs (Compute Thread Arrays) to collaborate within a Graphics Processing Cluster (GPC) and share distributed shared memory (DSMEM).

• Hopper also incorporated the Tensor Memory Accelerator (TMA) to address data movement bottlenecks.

  • TMA supports batched asynchronous data transfers and multicast, efficiently transferring data without occupying L2 cache and HBM bandwidth.

• The architecture also supported 8-bit floating-point formats (E4M3 and E5M2) with CUDA core assistance for enhanced precision.

Blackwell Architecture (2025): Tensor Memory and Advanced Optimizations

The fifth-generation Tensor Cores in the Blackwell architecture represent a revolutionary step, introducing Tensor Memory (TMEM).

• Each SM is equipped with 256KB of dedicated Tensor Memory, located near the computational units for faster and lower-power access.

• Matrices can reside in Tensor Memory, reducing data transfer overhead.

• Blackwell also incorporates CTA Pair mechanisms, single-thread MMA initiation, and inter-SM collaboration (MMA.2SM) for optimized matrix operations.

• It supports MXFP8, MXFP6, MXFP4, and NVFP4 floating-point formats, further enhancing precision and efficiency.

Structured Sparsity: Enhancing Computational Efficiency

Structured sparsity is a technique used to improve computational efficiency in NVIDIA Tensor Cores. However, its implementation and effectiveness have varied across different architectures.

Ampere Architecture: 2:4 Structured Sparsity

• Introduced 2:4 structured sparsity, pruning weight matrices so that two out of every four elements are zero.

• Theoretically, this could double Tensor Core throughput and halve memory usage.

• However, real-world results fell short due to challenges in maintaining model accuracy, sub-optimal cuSPARSELt kernel optimization, and TDP limitations.

Blackwell Architecture: 4:8 Structured Sparsity with NVFP4

• Introduced 4:8 structured sparsity for the NVFP4 data type, requiring two out of four pairs of consecutive elements to be non-zero.

• Designed to align with NVFP4's sub-byte characteristics.

• Despite being more flexible than 2:4 sparsity, it still faces challenges in balancing model accuracy and practical implementation.

Conclusion: A Legacy of Innovation

NVIDIA Tensor Core's evolution from Volta to Blackwell demonstrates the power of technological innovation. Each generation has broken down computational barriers, streamlined data processing, and improved computational performance. From the first half-precision matrix multiplication instructions to the dedicated tensor memory, NVIDIA has consistently pushed the boundaries of what's possible.
